Hopper bottom silos
HOPPER BOTTOM SILOS
Hopper Bottom Silos are used for the grain storage in the dry or wet process. These silos are performing well as storage for long-term grain storage, mostly used as a buffer silos at dryers or cleaning equipment. Discharge in the shape of a funnel allows for quick emptying the silo.
Depending on the working nature offered HOPPER BOTTOM SILOS are with diferent funnel angles 40°, 50°, и 60°
 THINKING ABOUT OUR CUSTOMERS
- Flat bottomed silos are made of corrugated structural steel S390GD galvanized with zink 450 gr/m2 or on request 600 gr/m2, Galfan coating or Magnelis
- The vertical pillars are made of structural steel S390GD galvanized with zink 450 gr/m2 (or 600 gr/m2 on request) which eleminate the effect of deformation the sheet after filling the equipments by grain.
- The use of corrugated steel ensures the construction durability, assuring longer lifetime of a silo, or less heating in the summer.
- The side plating assembly is so called "BRICK TYPE" so as to extend the life-time of the silo.
- Galvanized roof hatch and side hatch
- Galvanized poles and support structure.
- The funnel of the silo- galvanized structural steel S390GD
- Galvanized fasteners with hardness 8.8
- Set of anchors fixing a silo to the ground
 SLAV-CHAINS LTD PRODUCE ALL THE EQUIPMENT YOU NEED FOR YOUR GRAIN STORAGE PLANT:
- CHAIN CONVEYORS (REDLER) - they are used for horizonatal movement of grain and granular products. The CHAIN CONVEYORS produced by SLAV-CHAINS LTD are designed to ensure long-time hard work with minimum maintenance costs.
- BUCKET ELEVATORS - they are used for vertical movement of grain, seeds and granular products. The bucket elevators are used for filling the silo with the grain.
- UNLOADING AUGERS - mounted in the concrete floor they unload the silo.
- SWEEPT AUGERS - they sweept the grain from a bin floor
- VALVES - The two-way valves and three-way valves are used to diverting the product flow. Manualy or electricaly operated.
- SLIDING GATES -Produced in galvanized steel they can be manualy or electrically operated
- CATWALKS - galvanized, with hand railing and mounting brackets
- ELEVATOR TOWERS - Galvanized construction with stairs and operating platforms
- RECEIVING PIT- it can be concrete receiving pit or bolted construction produced from galvanized sheet metal
|
|
|
|
|
|
